Description
Characteristics
- Front actuation
- Low-noise lifting mechanism
- Hydraulic servo lifter for minimum actuation forces
- Flush actuation pneumatic
- Can be installed without tools
Technical data
- Flow pressure : 1-3 bar
- Actuation force :< 10 N
Scope of delivery
- Hydraulic servo lifter
- Water supply connection set
- Protection plate
- Mounting frame
- 2 distance bolts
- Assembly parts
Application purposes
- For flush actuation with Geberit Sigma concealed cisterns 12 cm
- For flush actuation with high actuating convenience
- Not suitable for public and semipublic areas
Spare Parts
Art. No. | Description |
243.084.00.1 | Protection plate for hydraulic servo lifter, for Geberit Sigma concealed cistern 8 cm |
242.819.00.1 | Protection plate for hydraulic servo lifter, for Geberit Sigma concealed cistern 12 cm |
242.813.FW.1 | Geberit flush plate Sigma70 for dual flush: brushed, easy-to-clean coated |
242.813.SI.1 | Geberit flush plate Sigma70 for dual flush: white |
242.813.SJ.1 | Geberit flush plate Sigma70 for dual flush: black |
242.813.SQ.1 | Geberit flush plate Sigma70 for dual flush: umber |
242.813.00.1 | Geberit flush plate Sigma70 for dual flush: customised |
242.814.00.1 | Mounting frame for Geberit flush plate Sigma70 |
813.514.00.1 | Spring for Geberit flush plate |
241.874.00.1 | Actuator rod set for Geberit flush plate |
243.297.00.1 | Geberit double pneumatic hose, green |
242.825.00.1 | Conversion set for hydraulic servo lifter, for Geberit Sigma concealed cistern 12 cm |
242.826.00.1 | Conversion set for hydraulic servo lifter, for Geberit Sigma concealed cistern 8 cm |
243.461.00.1 | Geberit hydraulic servo lifter, 1-3 bar |
242.820.00.1 | Geberit hydraulic servo lifter |
242.822.00.1 | Accessories set for Geberit hydraulic servo lifter |
243.170.00.1 | Support block for hydraulic servo lifter, for Geberit Sigma concealed cistern 12 cm |
243.171.00.1 | Support block for hydraulic servo lifter, for Geberit Sigma concealed cistern 8 cm |
243.169.00.1 | Support block for hydraulic servo lifter, for Geberit Omega concealed cistern |
243.347.00.1 | Support block for hydraulic servo lifter, for Geberit Sigma concealed cistern 8 cm |
242.824.00.1 | Reinforced braided hose for hydraulic servo lifter, for Geberit Sigma concealed cistern 12 cm |
242.823.00.1 | Reinforced braided hose for hydraulic servo lifter, for Geberit Sigma concealed cistern 8 cm |
Product Details
Art. no. | Material designation | Surface / Colour |
115.621.SI.1 | Glass | White |
115.621.SJ.1 | Glass | Black |
115.621.SQ.1 | Glass | Umber |
115.621.00.1 | - | Customised |
115.621.FW.1 | Stainless steel | Brushed, easy-to-clean coated |
Downloads
Click for Installation instructions
