Description
Characteristics
- Automatic flush actuation
- Infrared user detection
- Self-adjusting IR sensor
- Vandal-resistant
- Volume flow control via tap aerator
- Temperature presetting via mixer (only for models with mixer)
- Not possible to set just hot water or just cold water (only for models with mixer)
- Power supply by battery
- Can be refitted for mains operation
- Battery sufficient to activate the water flow 200000 times
- Warning when the battery is low
- Economy mode can be set
- Water saving due to quick-response two-beam scanning technology
- Functions can be set and queried with the Geberit Service Handy
- Water saver program can be set
- Interval flush program can be set
- Continuous flush can be set individually
- Flush actuation can be deactivated via Geberit Clean Handy
- Various functions can be set manually
- With integrated check valve
Technical data
- Battery type : CR-P2 (6 V)
- Operating voltage : 6 V DC
- Operating pressure : 0.5-8 bar
- Differentiated pressure CW/WW : ≤ 1.5 bar
- Ambient temperature : 1-40 °C
- Maximum operating temperature, water : 65 °C
- Maximum operating temperature, water, short-term : 90 °C
- Flow rate at 3 bar : 6 l/min
- Calculated flow rate : 0.07 l/s
- Minimum flow pressure for calculated flow rate : 0.5 bar
- Activation distance, adjustment range : 5-33 cm
- Activation distance, factory setting : 16-18 cm
- Interval flush, adjustment range : 1-168 h
- Interval flush, factory setting : 168 h
- Interval flush time, adjustment range : 3-180 s
- Interval flush time, factory setting : 3 s
- Material : Brass chrome-plated
Scope of delivery
- Basket filter
- Lithium battery, type CR-P2, 6 V
- Tap aerator key
- Fastening material
Application purposes
- For extracting tap water
- For public and semipublic areas
- For installation in washbasins or washtops
- For connecting cold and hot water (only for models with mixer)
- For connecting cold or mixed water (only for models without mixer)
- For use with stainless steel bowls
- Not suitable for small continuous flow heaters
Spare Parts
Art. No. | Description |
242.243.00.1 | Tap housing with opening, for Geberit washbasin tap type 185 |
242.244.00.1 | Tap housing without opening, for Geberit washbasin tap type 185 |
240.753.00.1 | Shut-off screw for Geberit washbasin taps types 85, 86, 185 and 186 |
242.030.21.1 | Tap aerator for Geberit washbasin taps types 6x, 8x and 18x: gloss chrome-plated, Flow rate=6l/min, Model=rigid |
242.834.21.1 | Tap aerator for Geberit washbasin taps types 6x, 8x and 18x: gloss chrome-plated, Flow rate=3.8l/min, Model=rigid |
242.645.21.1 | Tap aerator for Geberit washbasin taps types 6x, 8x and 18x: gloss chrome-plated, Flow rate=1.9l/min, Model=rigid |
243.626.21.1 | Tap aerator for Geberit washbasin taps types 6x, 8x and 18x: gloss chrome-plated, Flow rate=1.3l/min, Model=rigid |
242.247.00.1 | Mixer set for Geberit washbasin taps types 185 and 186 |
242.248.00.1 | Mixer handle set for Geberit washbasin tap type 185 |
241.655.00.1 | Temperature indicator for Geberit washbasin taps type 85-88, 185 and 186 |
242.251.00.1 | Electronics module for Geberit washbasin taps types 185 and 186 |
242.240.00.1 | Battery holder for Geberit washbasin taps types 185 and 186 |
242.666.00.1 | Geberit lithium battery, 6 V |
240.747.00.1 | Power supply adaptor for Geberit washbasin taps type 81-88, 185 and 186 |
242.570.00.1 | Geberit power adaptor eco |
241.630.00.1 | Power supply unit plug 230 V, for Geberit washbasin taps types 85, 86, 185 and 186 |
242.349.00.1 | Extension cable for power supply unit, for Geberit washbasin taps types 8x and 18x |
242.250.00.1 | Sealings and check valve set for Geberit washbasin taps types 185 and 186 |
242.242.00.1 | Reinforced braided hose, cold water, for Geberit washbasin taps types 185 and 186 |
244.004.00.1 | Geberit basket filter set (2 pc.) |
242.241.00.1 | Reinforced braided hose, hot water, for Geberit washbasin taps types 185 and 186 |
243.757.00.1 | Connection set made of copper, for Geberit washbasin taps types 185 and 186 |
Conversion set electrical generator for Geberit lavatory taps | |
241.649.00.1 | Fastening set for Geberit washbasin taps types 85, 86, 185 and 186 |
241.672.00.1 | Power supply unit for Geberit washbasin taps type 85-88, 185 and 186 |
242.266.00.1 | Solenoid valve for Geberit washbasin taps types 185 and 186 |
Product Details
Art. no. | Surface / Colour | Mixer |
116.235.21.1 | Gloss chrome-plated | Without mixer |
116.245.21.1 | Gloss chrome-plated | With mixer |
116.255.21.1 | Gloss chrome-plated | With mixer and handle |
Downloads
Click for Installation instructions
