Description
Characteristics
- Quality-monitored in accordance with EN 274-3
- Push actuation aligned with bathtub surface
- With overflow
- Double-sided seals on drain and overflow
- Overflow head with extendible mount can be fastened
Technical data
- Discharge rate : 1 l/s
- Overflow discharge rate : 0.65 l/s
- Depth of water seal : 50 mm
Scope of delivery
- Waste outlet
- Trap
- Straight connector made of PE-HD, ø 43 mm
- Ready-to-fit set
- Protection box
- Fastening material
Application purposes
- For bathtubs made of steel, plastic or cast iron
- For standard-size bathtubs
- For bathtubs with valve hole ø 52 mm
Spare Parts
Art. No. | Description |
241.715.11.1 | Geberit waste plug: white alpine |
241.715.21.1 | Geberit waste plug: gloss chrome-plated |
241.715.45.1 | Geberit waste plug: gold-plated |
241.715.46.1 | Geberit waste plug: matt chrome-plated |
241.717.00.1 | Geberit waste outlet |
240.569.00.1 | Geberit straight connector with ball joint |
854.454.00.1 | Geberit connection bend with union nut made of PE: d=40-50mm |
150.249.16.1 | Geberit connection bend 45° with union nut: black |
241.675.00.1 | Geberit straight connector with union nut |
241.995.00.1 | Geberit compression joint |
854.405.06.1 | Geberit overflow bend: d=32mm, granite grey |
854.406.06.1 | Geberit union nut: granite grey |
894.050.16.1 | Geberit compression ring: black |
891.210.00.1 | Geberit compression seal |
362.790.00.1 | Geberit HDPE round cord ring: d=32mm |
241.718.00.1 | Geberit overflow bend |
240.461.00.1 | Geberit bellows for overflow head |
241.712.16.1 | Section seal for Geberit bathtub drain with push actuation Push Control: black |
241.713.21.1 | Flange with compression gasket, for Geberit bathtub drain with push actuation Push Control: gloss chrome-plated |
241.714.11.1 | Rotary button for Geberit bathtub drain with push actuation Push Control: white alpine |
241.714.21.1 | Rotary button for Geberit bathtub drain with push actuation Push Control: gloss chrome-plated |
Product Details
Art. no. | Surface / Colour |
150.770.21.1 | Gloss chrome-plated |
